Parameter Description
- Tianxianwei's business scope includes LCD/LCM module development, PCBA motherboard development and installation. Over the past 11 years, Tianxianwei has developed thousands of LCD and LCM products for industrial, household appliances, medical, education and other fields, used in industrial, kitchen appliances, instrument and household appliances, consumer electronics, medical equipment securityaccess control, children's education, medical instruments, automotive intelligent interconnection and other applications.2.TXW103002S0 is a 10.25-inch long bar scale full-color TFT LCD display screen with a resolution of 1920 * 720, IPS full angle high-definition and high brightness display effect, wide temperature -30+85 working temperature, and brightness of 1000cd/m ².
- This product is independently designed, developed, and produced by Shenzhen Tianxianwei Technology Co., Ltd. It provides professional full process technical support services, first-class production quality control, and professional after-sales service guarantee
- This product is widely used in car dashboard, car navigation, 3D printers and other products.
Features:
- Product Name: Bar Type TFT
- Model Number: TXW103002S0
- ITEM: Sandard Value
- Lumens degrees: 1000cd/m²
- Pixel arrangement: RGB Stripe
- Size: 10.25 inches
- Tft Lcd Display
- High-brightness Lcd Display
- Hd Display Mipi Interface Tft Lcd Display
Technical Parameters:
Bar Type TFT Technical Parameters
| LCM Interface | LVDS BIT Interface |
| ITEM | Standard Value |
| Active Area | 243.648*91.368 |
| Viewing Direction | ALL O'CLOCK |
| Number of Pixels | 1920*720 |
| Model Number | TXW103002S0 |
| Mechanical Outline Size (W*H*T) | 258.8*111.1*7.55 |
| Size | 10.25 |
| Lumens Degrees | 1000cd/m² |
| Pixel Arrangement | RGB Stripe |
Keywords: TFT LCD Display, High-Brightness LCD Display, High Brightness Liquid Crystal Display
Applications:
TXWEI Bar Type TFT - High-brightness Lcd Display
The TXWEI Bar Type TFT is a high-brightness LCD display that is ideal for a variety of applications and scenarios. With its sleek design and advanced features, it is the perfect choice for those looking for a high-quality display solution.
Product Attributes:
- Brand Name: TXWEI
- Model Number: TXW103002S0
- Place of Origin: Guangdong, China
- Certification: CE, ROHS, FCC
- Minimum Order Quantity: Negotiable
- Price: Negotiable
- Packaging Details: Cardboard
- Delivery Time: 16 days
- Payment Terms: L/C, TT, D/P
- Supply Ability: 10,000 pcs
- Lumens degrees: 1000cd/m²
- LCM interface: LVDS BIT Interface
- Number of pixels: 1920*720
- Viewing direction: ALL O'CLOCK
- Pixel Pitch (W*H): 0.13269*0.13269
The TFT LCD Module by TXWEI, model number TXW103002S0, is a cutting-edge display technology that offers high performance and versatility. Designed and manufactured in Guangdong, China, this product has gained certifications such as CE, ROHS, and FCC, ensuring its quality and reliability.
One of the key features of the TFT LCD Module is its brand name, TXWEI, known for its excellent quality and innovative products. This module boasts a luminous degree of 1000Cd/m², making it ideal for use in both indoor and outdoor environments. Its operating temperature range of -20+70 degrees makes it suitable for use in extreme conditions.
With a size of 10.25 inches, the TFT LCD Module offers a resolution of 1920*720 pixels, providing sharp and clear images. Its touch screen display feature allows for user-friendly interaction, making it suitable for applications that require a touch interface.
The TFT LCD Module is a customizable product, allowing users to adjust various display parameters according to their specific needs. This makes it a popular choice for custom tft display designs. The product also offers high brightness and contrast, making it suitable for use in both indoor and outdoor environments
The delivery time for the TFT LCD Module is 16 days, which is relatively quick compared to other display modules in the market. The payment terms include L/C, TT, and D/P, providing flexibility to customers. With a supply ability of 10000pcs, TXWEI ensures that their products are readily available for their clients.
